Description
- Features – Single channel output. – Digital or pointer meter shows the voltage and current values. – Voltage/current adjust knob with rough and meticulous adjustable potentiometers can outputs constantly with high resolution.
- A power supply of universal type with simplify function and high cost-effective. – Current limiting protection and users can set the current limiting protection point arbitrarily. – Internal radiator and electronic temperature control cooling fan. – Opposite polarity protection. – Plastic panel of the equipment is modern, simple and beautiful.
- Specification – Input voltage: 220V AC ±10% 50Hz (also can be 110V AC±10% 50Hz if required) – Voltage output: 0 – 30V – Current output: 0 – 5A – Operating temperature: -10C – 40C – Relative humidity: < 90% – Storage temperature: -10C – 40C – Relative humidity: < 80% – Voltage stability: ≤0.01% + 2mV – Load stability: ≤0.01% + 2mV – Resume time: ≤100us.
- Ripple noise: ≤1mVRMS (RMS) – Temperature coefficient: ≤200PPM/C – Current stability: ≤0.1% + 3mV – Load stability: ≤0.2% + 3mV – Ripple noise: ≤2mARMS – Voltage display accuracy: Three light-emitting diode, ±1%±1 unit – Pointer table: ±2.5% – Current display accuracy: Three light-emitting diode, ±1%±1 unit – Pointer table: ±2.5%.
- Package Included: 1 * RXN-305D Adjustable Linear DC Power Supply with Screen Display Voltage Current 1 * Power Cord 1 * Alligator Crocodile Clip.
